Đặc tính kỹ thuật
|Fixed Ports||8 1000BASE-T ports|
1 SFP port
1 SFP+ port (non-combo)
|WAN Ports||Upto 6|
|Hard Disk||Standard 1TB|
|Performance & Feature|
|Performance||4000Mbps (1518 bytes)|
622Mbps (64 bytes)
|Recommended Concurrent User||1000|
|Portal Authentication Capacity||1000 (Max Concurrent Users)|
|Portal Authentication Type||Username/Password Auth (Local, Windows-based AD/LDAP Integration)|
Guest Voucher (Ruijie Cloud required)
|Seamless Authentication (Portal)||Support|
|Cache Resources||Windows System Patches|
|Network Protocol||Support TCP/IP protocols, including IP, ICMP, TCP, UDP, etc.|
Support multiple routing protocols, including static routing, RIP (V1 / V2) and OSPF
Support DHCP Relay and DHCP Server
Support PPPoE Client
Support NAT and multiple NAT ALG including FTP, H.323, DNS, etc.
Support ARP, trusted ARP, proxy ARP, etc.
Support Ping and Traceroute fault detection
|Application Visibility||Support self-developed 43 types of applications / more than 120 application features, customizable protocol identification:|
P2P: BitTorrent, eMule, Thunder, EDONKEY, FlashGet & etc.
Multimedia: YouTube, Facebook Video, WebEx Conference & etc.
Social Media: Facebook, Twitter, LinkedIn, Pinterest & etc.
VOIP/Chat: Skype, Viber, Google Hangout, Jabber, Facebook Messenger & etc.
Instant Messaging/Email: Gmail, MSN, QQ, YAHOO & etc.
Software Update: Window, McAfee, Kaspersky, ESET & etc.
Cloud-based File Collaboration: GoogleDrive, Dropbox, OneDrive, iCloud & etc.
Enterprise Application：HTTP, FTP, SMTP, POP3, IMAP, Telnet, LOTUS-NOTES, SQL Server, Oracle, Mysql, HTTPS & etc.
|URL Filtering||Support HTTP/HTTPS domain filtering|
Support remote HTTP automatic URL library upgrade
Local log storage (NAT log, traffic log, URL log, etc.)
Support storage on external log server
|WAN Load Balancing||Support (upto 6 WAN Port)|
RIP (Graceful Restart)
OSPF (Graceful Restart)
|IPsec VPN Tunnel||600|
|Network Security||Anti-ARP Spoofing|
Defense against malicious attacks from internal and external networks
Support secure address binding
Block WAN Ping
Prevent Port Scan Attack
Prevent Fragmentation Attack
Prevent ICMP Flood Attack
Prevent Teardrop Attack
Prevent Ping of Death Attack
Prevent Land Attack
Prevent Smurf / Fraggle attack
Prevent SYN Flood Attack
|Layer 2 Features||Support Bridging|
Support LAN Port Aggregation
|Ruijie Cloud Integration Feature||Support device health monitoring status|
Support centralized configuration change management & backup
Support Top 10 Application/User traffic visualization
Support device firmware management
Support event-based alarm notification
|Other Features||Integrate with AAA software to support multiple authentication modes|
|Service and Support||Support push advertising page|
Support multi-link load balancing
Support remote HTTP online upgrade for signature library, software version, etc.
Lifetime Free signature library upgrade
|Dimensions (W x D x H)||440×200×43.6 mm|
|Operating Temperature||0°C to 40°C|
|Operating Humidity||10% to 90%RH|
